Rippa

R22 PRO

R22 PRO

Regular price 18.490,00 EUR
Regular price 19.490,00 EUR Sale price 18.490,00 EUR
Sale Sold out
excl. MwSt

In stock

The Rippa R22 PRO is a powerful and versatile mini excavator, ideal for medium to large construction and landscaping projects. With its robust design and powerful Kubota diesel engine, it combines efficiency, precision, and reliability for professional use.

With an operating weight of 2,371.5 kg, a digging depth of 2.29 meters, and a digging force of 18.4 kN, the R22 PRO easily handles demanding tasks and provides maximum control in every movement.

Standard features include:

✔ 40 cm toothed bucket for precise digging
✔ Powerful Kubota diesel engine (Euro 5 certified)
✔ High digging force for efficient performance
✔ Durable construction for long-lasting reliability

Additional accessories, such as various buckets, grapples, or quick couplers, can be found in the Accessories section on our website.

R22 PRO – Specifications

Basic Parameters EU / US
Operating Weight 2371.5 kg / 5228 lb
Bucket Capacity 0.049 m³ / 1.9 ft³
Travel Speed (low/high) 0–1.5 / 2.8 km/h / 0–0.93 / 1.71 mph
Gradeability 30 %
Ground Pressure 33.4 kPa / 4.84 psi
Max. Digging Force 18.4 kN
Max. Digging Radius 4143 mm / 163.1 in
Max. Digging Depth 2293 mm / 90.3 in
Max. Digging Height 3761 mm / 148.1 in
Max. Unloading Height 3496 mm / 138.9 in
Track Extension Range 1300–1500 mm / 51.2–59.1 in
Engine EU / US
Brand Kubota
Model D1105
Max. Horsepower 24.8 hp
Max. Power 18.2 kW
Max. Speed 3000 rpm
Displacement 1.23 L / 0.31 gal
No. of Cylinders 3
Cooling Water-cooled
Engine Oil (change amount) 4.2 L / 1.1 gal
Fuel Diesel
Fuel Grade No. 0 / -10
Theoretical Fuel Consumption 1.3–1.5 L/h / 0.34–0.40 gal/h
Dimensions EU / US
Transport Length 2824 mm / 111.2 in
Transport Width 1300 mm / 51.2 in
Transport Height 2361 mm / 92.9 in
Min. Ground Clearance 450 mm / 17.7 in
Bucket Width 450 mm / 17.7 in
Boom Length 1350 mm / 53.1 in
Arm Length 1250 mm / 49.2 in
Dozer Blade Width 1300 mm / 51.2 in
Hydraulic System EU / US
Main Pump Type/Model Load sensitive variable piston pump / 28
Main Pump Brand Taifeng
Max. Flow 67.2 L/min
Multi-way Valve 9-way hydraulic multi-way valve
Multi-way Valve Brand Taifeng
Rated Pressure 18 MPa
Max. Pressure 20 MPa
Travel Motor Type LTM03CDK
Travel Motor Brand Likuchuan
Motor Displacement (travel) 11–20
Slewing Motor Type Likuchuan
Slewing Motor Displacement 15.1
